Equal cross 18L VOSS KS18L
Equal cross 18L VOSS KS18L
Equal cross 18L VOSS KS18L
Equal cross 18L VOSS KS18L
Aftermarket
KS18L

Equal cross 18L VOSS KS18L

€29.00

(€24.17 tax excl.)

  • Secure payments
  • Simplified returns
  • Wide selection of products
  • Fast delivery

Product description

Shape : Cross

Connection no 1 type : Cutting ring

Connection no 1 type - male/female : Female

Connection no 1 diameter : 18 mm

Connection no 1 thread diameter : M26

Connection no 1 thread pitch : 1.50 mm

Connection no 1 thread type : Metric

Connection no 1 wrench size : 32.0 mm

Connection 2 type : Cutting ring

Connection 2 type - male/female : Female

Connection 2 diameter : 18 mm

Connection 2 thread diameter : M26

Connection 2 thread pitch : 1.50 mm

Connection 2 thread type : Metric

Connection 2 wrench size : 32.0 mm

Connection 3 type : Cutting ring

Connection 3 type - male/female : Female

Connection 3 diameter : 18 mm

Connection 3 thread diameter : M26

Connection 3 thread pitch : 1.50 mm

Connection 3 thread type : Metric

Connection 4 type : Cutting ring

Connection 4 type - male/female : Female

Connection 4 diameter : 18 mm

Connection 4 thread diameter : M26

Connection 4 thread pitch : 1.50 mm

Connection 4 thread type : Metric

Connection no 1 center to end distance : 23.5 mm

Pipe diameter : 18 mm

DIN standard : 2353 2401

Inside diameter : 18 mm

Total length : 62 mm

Body height : 24 mm

Surface treatment : Zinc Nickel-plated

Max working pressure : 315 BAR

Series : L

Product features

Information Aftermarket
Brand VOSS
This product is adaptable, which means that it can be adapted to the models of the manufacturers specified above, non-exhaustive list.
